Broaching¶
| Broach Size A [mm] | Tolerance A [mm] | Drill Size B [mm] | Broach Depth C [mm] | Drill Depth D Min [mm] |
|---|---|---|---|---|
| 1.5 | 1.5 / 1.56 | Ø1.55 +/-0.05 | 1.5 +/-0.1 | 2.25 |
| 2 | 2.0 / 2.07 | Ø2.05 +/-0.05 | 2.0 +/-0.1 | 3.00 |
| 2.5 | 2.5 / 2.60 | Ø2.6 +/-0.05 | 2.5 +/-0.1 | 3.75 |
| 3 | 3.0 / 3.10 | Ø3.1 +/-0.05 | 3.0 +/-0.1 | 4.50 |
